Sinodrills T30-11 Anchor Bar
- Materials comply with G30.18, ASTM 615, and ASTM A123/A153 standards.
-
Size: T30-11
-
O.D.: 30 mm
-
I.D.: 11 mm
-
Ultimate Load: 320 kN
-
Yield Load: 260 kN
-
Weight: 3,3 kg/meter
-
Thread direction: Left hand / Right hand
Sinodrills T30-11 Anchor Bar.
Materials comply with G30.18, ASTM 615, and ASTM A123/A153 standards.
T thread Bars are part of the Self Drilling Anchor system Sinodrills. This is a hollow anchor bar that allows drilling, anchoring and grouting in a single operation.
The length of the bars is determined when ordering and depends on the operating conditions and the type of equipment used.
- Size:T30-11
- O.D.:30 mm
- I.D.:11 mm
- Ultimate Load:320 kN
- Yield Load:260 kN
- Weight:3,3 kg/meter
- Thread direction:Left hand / Right hand
