Dia 25mm – 500 Thread Bar
- Materials comply with G30.18, ASTM 615, and ASTM A123/A153 standards.
-
Grade: PSB500
-
Diam: 25 mm
-
Yield/Tensile: 246 / 309 kN
-
Weight: 4,1 kg/meter
-
Technology: Hot rolled, right hand
-
Material: Carbon Steel; Alloy Steel
-
Length: 9m, 12m or as per customer’s requirements
- Surface: Self Color; Zinc Plated; HDG; Epoxy Coating
Dia 25mm – 500 Thread Bar
Materials comply with G30.18, ASTM 615, and ASTM A123/A153 standards.
The PSB500 thread bar is made of black steel with a continuous right-handed thread along the entire length of the bar.
The continuous threading allows the cutting of the bar with different lengths according to the design requirements, and it also improves the adhesion between the bar and grouting.
Typical Applications:
1. Rock bolts
2. Marine tie rod
3. Concrete anchoring system
4. Formwork tie bar
5. Post-tensioning systems
6. Geotechnical systems
7. Mining & Tunneling
Thread Bar Coating for Corrosion Protection:
Black or plain: Standard coating
Coating: galvanized(on request)
Coating: epoxy coating(on request)
- Grade:PSB500
- Diameter:25 mm
- Yield/Tensile:246/309 KN
- Weight:4,1 kg/meter
- Technology:Hot rolled, Right hand
- Material:Carbon Steel; Alloy Steel
- Length:9m, 12m or as per customer's requirements
- Surface:Self Color; Zinc Plated; HDG; Epoxy
